DESCRIPTION :
The NORDICA double head steel cutting machine is equipped with a fixed unit on the left and automatic movable right head which is digitally controlled. It is also equipped with pneumatically rotating heads from 45° to 90° to 135° inwards. Two speed 1.8/2.5 kW three phase saw motors are included. Equipped with 4 horizontal clamps with low pressure valve, cutting area protection, 2.5m movable head conveyor, 350 mm HSS blades, electric pump for the blade lubrication and cooling round off this unit.
EQUIPPED WITH ELECTRONIC V8 TOUCHSCREEN CNC ABLE TO: • Manage single cuts • Store 100 profile codes and their values • Save cutting list already calculated • Manage frame typologies • Metric ruler with reading index • Save cutting list from USB
COMPONENTS SUPPLIED:
1 m fixed head conveyor
OPTIONS:
5 m cutting length
WINDONS 10 touchscreen control
Automatic cutting without operator attendance
