MATRIX 8 DOUBLE HEAD 45- 90 UPSTROKING SAW 550 DIA BLADE DIGI MANUAL

  • image
  • image
  • image
  • image

Description:

DESCRIPTION :

  • The saw machine is used for cutting alu - ally and curtain wall profiles
  • Dedicated high - quality imported aluminium carbide saw blades , ensuring precise cutting performance
  • High precision spindle, rotate the blade to ensure a smooth and effective to improve the surface quality of the cut surface profile
  • The two - way loaction and clamping features high precision and steadliness
  • Automatic angle cutting change in 45 and 90 .
  • The profile cutting  size adopts the digital technoque to ensure high efficency and accuracy
  • The two cutting units can work simulataneously or separately.


SPECIFICATION -

Electric power - 380V 50Hz 2*3Kw

Speed - 2840r/min

Cutting angle - 45-90

Blade Dia-550 * 30mm

Cutting length - 450-4200 mm

Cutting width - 260 - 310 mm

Cutting Height - 120 - 155 mm

Weight - 1900 kgs

Outside Dimension - 5850*1650*1550 mm
