ANDROMEDA 700 UPSTROKE SAW

Country:

Description:

DESCRIPTION -

ANDROMEDA 700 COMPOUND MITER SAW

The ANDROMEDA 700 is a single head upcut compound miter saw complete with a 700 mm carbide tipped blade for precision cutting of Aluminum and PVC material.

The fully adjustable blade advancement system lets you control the stroke of the hydro-pneumatic cylinder.

The tilting of the blade is pneumatically operated from 90 to 45 while the intermediate angles can be obtained with manual mechanical stop the rotation of the table is manual with fixed stops at 45/90/135 intermediate positions from 22.5 on the right to 157.5 on the left by pneumatic locking.

This machine is equipped with a digital angle display to read the rotation angle for easy operator use.

The start cycle of the blade is determined through an inverter, which allows the set up of blade advancement only when the desired RPM is reached this device allows obtaining both a better starting and stopping of the blade.

The upward movement of the blade cuts with little pressure on the profile and facilitates precise and accurate cuttings. Dust collection can be achieved through the evacuation port located on the rear of the machine.

Specification
Video

COMPONENT SUPPLIED:
• Carbide saw blade 700 mm
• Hydro-pneumatic blade feeding
• Full, pneumatic actuated, protection enclosure
• N.2 Horizontal clamps
• N.2 Vertical clamps
• Pneumatic mist spray
• Motor 7,5 Kw
• Blade speed 1500 RPM
• Rotation from 22.5to 157.5 the angle can be
read on a digital display, pneumatic locking.

• Tilting from 90 to 45intermediate angles
with mechanical stop
• Working pressure: 7 bar
