DESCRIPTION -
Relevence with CE standards
Quick adjustment bumpers for 15 degree,22.5 degree,30 degree,45 degree,60 degree,90 degrees
Tray fixing lever for intermediate grades
The saw output speed regular slow the speed in aluminium cuts and reduce engine loading
Diamond saw blade diameter 450mm
Measurement and transport conveyors are available as stanadard.(2mt.right-left)
OPTION -
Cooling system for aluminium profile cutting
Hydrocheak system for aluminium profile cutting.
Technical specifications -
Power supply: 440 V, 3ph, 50-60 Hz.
Power output: 1.1 kW.
Spindle speed: 2,810 r.p.m.
Air pressure: 6-8 bar.
Air consumption: 41 l/min.
Blade outer Radius : 420 mm.Blade inner Radius : 30 mm.
