Power Supply
|
3 phase 380v 50/60Hz
|
|
Total Power
|
13kw
|
|
Y Axis Hydraulic Cylinder Thrust
|
30T
|
|
Y Axis Hydraulic Cylinder Repeat Position Accuracy
|
?0.02mm
|
|
Maximum Torque of X axis
|
8000N.M(3 servo&hydraulic)
|
|
Three axis rotary speed
|
1-15r/min
|
|
Axis spacing
|
400-800mm
|
|
Min Bend Radius
|
R=150mm
|
|
Shaft Diameter
|
80mm
|
|
Dimension
|
1600*1500*1500mm
|
|
Total Weight
|
1800kgs
|
|
Max Cross-section of processed steel pipe
|
Square steel pipe80*80*6mm
|
|
Circular steel tubeΦ80*6mm
|
|
Machinable aluminum profiles
|
Max cross-sectional area WXH:18000mm²
|
|
Max width:200mm, Max axial height:250mm
|
