No
Name
Numerical value
1
Model
YLT-150T-60
2
Nominal pressure
1500KN
3
Slider stroke
90mm
4
Table length
3250mm
5
Height of lower die surface from
ground
1045mm
6
Punching diameter
16.5mm
7
Punching spacing
50mm
and 50mm multiples
8
Number of punching holes
1~60
9
Single stroke time
About 4 seconds
10
Operating voltage
380V/415V
11
Motor power
18.5KW
12
Overall dimensions (length * width
* height)
3600*1300*2550
13
Whole machine weight
?8000kg
