NOTCHING SAW MINI 100



Description:

Pneumatic carriage feed, manual height adjustment with hand wheel.

Technical Data-

Overall dimensions (LxWxH)800x1500x135

Weight 200kg.

Three phase motors 230-400V 50 Hz 1,1Kw(1,5hp)

Blade Spin2800 r.p.m.

Working pressure 7 bar.



Standard Equipment-

Nx2 Vertical pneumatic clamps

Working table adjustable with handwheel

Adjustment of the clamps speed

Full protection of the blades feeding speed

Nx2Three phase motors

Air filter with adjustment of the pressure

Service spanners.

OPTIONAL-

Side stop complete with measuring gauge

Single phase motors

Oleo-pneumatic cylenders of the blades and spray mist lubrification horizontal pneumatic clamps (only TR-V).
