Description:
Technical data
• Machine totally enclosed
• Sliding of the sawing carriage by means of ricirculating balls bearings on rectified and temperated guides Clyinder stroke 700mm
• Adjudtable feeding of the sawing carricage 4-10 mt/min
• Blades tilting range+/-45 degree by means of the hand wheel
• Possibility to perform cuts at any intermediate degrees
• Adjustable working bench in terms of hight and depth by means of hand wheels
• Tilting fence on the working bench at 45 degree/90 degree/-45 degree
• Max.profile hight 155mm • Max.profile width 250mm
• Max.depth of cut in horizontal 135mm
• Max.depth of cut in vertical 160mm
• 2,2 kw (3 HP) self braking motors-2800r.p.m.
• Sawblade’s bore dia 30mm • Working pressure 7 bar
• Overall dimensions:3140*1380*1800mm • Weight:1500kg Standard Equipment
• Nr.1 TCT saw Blades dia 500mm • Nr.1 TCT saw Blades dia 500mm
• Pneumatic lubrification by means of nebulizer
• Waste retrieval front tank on wheels
• Nr. Waste retrieval tanks on the sides
