- 7 touch screen display operator interface and push buttons for all functions of the sawing machine. It is simple and intuitive, it guarantees a reliable use and it controls all cutting parameters in real time. - Protective guards for the operator
- Field bus control system with double microprocessor with serial connection.
- Structure in sturdy cast iron G25, to absorb vibrations and give the machine a better cutting stability and longer blade life.
- Ergonomically positioned on the front side of the machine, the control panel allows for easy viewing of machine operations and job set up.
- Infinitely adjustable cutting speed from 15 to 100 m/min controlled by an AC inverter drive system.
- Automatic acquisition of the actual starting point of the cut.
- Saw frame movement on linear guide with ballrecirculating pre-charged slide.
- Cutting head and feeding vice positioning with joystick.
- Automatic adaptive shearing stress control system with servovalve mounted directly on the cylinder.
- Manual band tension with LED display on control panel.
- Hydraulic power pack to supply the saw frame. and the feeding and cutting vices. Variable pressure adjusters allow to set the clamping force.
- Feeding length up to 500 mm in a single stroke driven by a stepper motor and ball screw assembly.
- Automatic retract of back jaw feeder vice to help the feed-in of bars heavily deformed.
- Driving pulley secured by tapered hub to ensure a strong fastening still allowing axial adjustment.
- Adjustable blade-guide heads in steel with carbide guide inserts, coolant taps for the traditional lubrication and preset to install the mist lubrication (OPTIONAL).
