Main Features:
1.Adopts advanced industrial CNC system and a user-friendly man-machine interface, enabling simple and convenient equipment operation.
2. Suitable for milling, drilling and other processing operations of light alloys such as aluminum alloy profiles, industrial aluminum profiles, aluminum-wood composite profiles, copper profiles, as well as V-PVC profiles.
3. Equipped with imported high-precision linear motion guides, ball screws, gear racks and servo motor, ensuring stable operation, high positioning accuracy and machining precision.
4. Utilizes high-quality high-speed variable-frequency electric spindles to guarantee machining stability, smooth rotation, low noise and strong cutting capacity.
5. It has a program storage function for easy and efficient use.
Parameter Details:
|
Input Power
|
380V 50Hz(can be customized 220V)
|
|
Main Spindle Power
|
2.2KW
|
|
Working Pressure
|
0.5~0.8MPa
|
|
Air Consumption
|
100L/min
|
|
Miller Rotary Speed
|
0-18000r/min (Variable Frequency Adjustable)
|
|
Tabletop Design
|
-90°-0°+90°
|
|
Max Processing Width
|
150mm if 3-side turning is 130mm
|
|
Max Processing Height
|
140mm
|
|
X-axis stroke 600mm, X-axis speed 0-10m/min
Y-axis stroke 350mm, Y-axis speed 0-10m/min
Z-axis stroke 300mm, Z-axis speed 0-10m/min
|
|
Machine Size
|
1200mm*1200mm*1600mm
|
Some Spare Parts Details:
|
System
|
Honghai System
|
China
|
|
Electric Parts
|
SCHNEIDER
|
France
|
|
Screen
|
10 cun
|
China
|
|
Solenoid Valve
|
AC220v
|
China
|
|
Pneumatic Parts
|
?
|
China
|
|
Cylinders
|
?
|
China
|
|
Oil-Water Separator
|
AFC2000
|
China
|
|
Main Spindle Motor
|
2.2KW
|
China
|
|
Diameter Miller
|
8X100
|
China
|
